Fasco K100 Motor | Fasco C-Frame Vent Fan Motor .73 amps 2750 RPM 115V (CW rotation)

Fasco K100 Motor | Fasco C-Frame Vent Fan Motor .73 amps 2750 RPM 115V (CW rotation)

The Fasco K100 is a C-frame vent fan motor designed for various fan applications including bath fans, hood fans, and humidifier/dehumidifiers. It replaces multiple Fasco models such as 7158-1185, 0648-0027, and 8767-8225, offering reliable clockwise rotation when facing the shaft.

Key Specifications

• Horsepower: 1/100 hp
• RPM: 2750
• Voltage: 115 V
• Amperage: 0.73 A
• Frame / Diameter: C-Frame, Iron Stack Size 0.62"
• Shaft Dimensions: 0.181" diameter x 1.05" length
• Rotation: Clockwise (CW)
• Enclosure: Continuous Duty - Class B Insulation

Product Features & Fitment

This motor features a 2-stud mounting system with studs spaced 1 7/8" on center for secure installation. It includes a standard 2-prong plug for easy electrical connection. Rotation direction is determined when facing the shaft, ensuring proper fitment for specific fan applications.

Cross Reference

• Fasco 7158-1185, 0648-0027, 8767-8225, 642, 643, 645, 646, 647, A647, B647, 648S, 664, A664, 667, A667, B667 and many others
