Fasco D1055 Direct OEM Replacement 1/12 hp 1375 RPM 3-Speed 115 Volts

Fasco D1055 Direct OEM Replacement 1/12 hp 1375 RPM 3-Speed 115 Volts

This Fasco D1055 motor is a direct OEM aftermarket replacement designed for HVAC and industrial applications. It is compatible with multiple OEM part numbers and provides reliable performance in systems requiring a compact, multi-speed motor.

Key Specifications

• Horsepower: 1/12 hp
• RPM: 1375
• Voltage: 115 Volts
• Amperage: 1.1 amps
• Enclosure: Open Ventilation - Air Over
• Frame / Diameter: 5 inch motor diameter
• Shaft Dimensions: Double shaft, 9" x 1/2" diameter x 9"
• Bearings: Sleeve bearings

Product Features & Fitment

This PSC style motor includes a capacitor and features four selectable speeds: High, Medium High, Medium Low, and Low. It is designed with resilient mounts and a bolt circle diameter of 4.62" for secure installation. The motor length excluding shafts measures 3-3/8" with a shaft height of 3.5". It comes with 47" power leads and is thermally protected for safe operation. Suggested replacements include IEC 4127, K48HXTSR-4127, and several other OEM part numbers.

Cross Reference

• FASCO D1055
• Motor Manufactured by PEMS

Warranty

1 Year Manufacturer Warranty
