Fasco D148B Motor | 1/10 hp 1050 RPM CW 5" Diameter 115 Volts

Fasco D148B Motor, 1/10 HP, 1050 RPM, 115V, 5" Diameter

The Fasco D148B direct-drive fan motor is engineered for reliable, efficient performance in residential and light commercial HVAC applications. Built with durable ball bearings and an open ventilated air-over enclosure, this 1/10 HP motor delivers consistent airflow for compatible blowers and HVAC systems.

Key Specifications

• Part Number: D148B
• Horsepower: 1/10 HP
• RPM: 1050
• Voltage: 115 Volts, 60 Hz
• Amperage: 1.61 Amps
• Enclosure: Open Ventilation - Air Over
• Frame / Diameter: 5" Diameter
• Shaft Dimensions: 3/8" diameter x 3 1/2" length
• Rotation: Clockwise (CW) Shaft End
• Bearings: Ball Bearings

Product Features & Fitment

Featuring ball bearings and a 5-inch diameter motor frame, this 115V motor is constructed for smooth operation and extended service life. It operates at 1050 RPM with clockwise (CW) rotation referenced from the shaft end and includes a 3/8" x 3 1/2" shaft. The open ventilation air-over enclosure relies on the air stream to maintain safe operating temperatures in furnace blowers, unit heaters, and air handlers.
