FD12AM2P4ZRS Nidec 1/2 HP 1800 RPM ( 1 speed) 115/230V 48YZ Frame TEAO Farm Hatcher Motor
FD12AM2P4ZRS Nidec 1/2 HP 1800 RPM ( 1 speed) 115/230V 48YZ Frame TEAO Farm Hatcher Motor
FD12AM2P4ZRS Nidec 1/2 HP 1800 RPM ( 1 speed) 115/230V 48YZ Frame TEAO Farm Hatcher Motor
FD12AM2P4ZRS Nidec 1/2 HP 1800 RPM ( 1 speed) 115/230V 48YZ Frame TEAO Farm Hatcher Motor

Nidec

FD12AM2P4ZRS Nidec 1/2 HP 1800 RPM ( 1 speed) 115/230V 48YZ Frame TEAO Farm Hatcher Motor

(No reviews) Write a Review
$494.50
$441.60
SKU FD12AM2P4ZRS
Shipping Free Shipping
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 115/230V
Horsepower 1/2 HP
RPM 1800
Phase Single Phase
Frame 48YZ
Enclosure TEAO
Hertz 60 Hz
Type PSC (Permanent Split Capacitor)
Amperage 5.0/2.5 Amps
Bearings Ball Bearings
Speeds 1-Speed
Rotation Reversible
Adding to cart… The item has been added
Description

    1/2 HP 1800 RPM (1 speed), 5.0/2.5 amps 115/230V Volts 60 Hz PSC Motor
    48YZ Frame, Rolled Steel, Keyed Shaft 1/2" diameter x 1 3/8" long
    Service Factor = 1.0, Overload Protection: Auto
    BAND Mount, Ball Bearings, Class A Insulation, Reversible Rotation
    1 Year Manufacture Warranty

Single phase farm fan motor for Hatcher and Setter motors in poultry and livestock houses. Wiring diagram on motor name plate. TEAO = Totally-Enclosed Air-Over, K055BSY6215022B

Specifications
Voltage 115/230V
Horsepower 1/2 HP
RPM 1800
Phase Single Phase
Frame 48YZ
Enclosure TEAO
Hertz 60 Hz
Type PSC (Permanent Split Capacitor)
Amperage 5.0/2.5 Amps
Bearings Ball Bearings
Speeds 1-Speed
Rotation Reversible
!
