FD34BA2P Nidec 3/4 HP 1800 RPM ( 1 speed) 115/230V 56 Frame TEAO Farm Fan Motor
FD34BA2P Nidec 3/4 HP 1800 RPM ( 1 speed) 115/230V 56 Frame TEAO Farm Fan Motor
FD34BA2P Nidec 3/4 HP 1800 RPM ( 1 speed) 115/230V 56 Frame TEAO Farm Fan Motor
FD34BA2P Nidec 3/4 HP 1800 RPM ( 1 speed) 115/230V 56 Frame TEAO Farm Fan Motor

Nidec

FD34BA2P Nidec 3/4 HP 1800 RPM ( 1 speed) 115/230V 56 Frame TEAO Farm Fan Motor

(No reviews) Write a Review
$282.90
$253.00
SKU FD34BA2P
Shipping Free Shipping
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 115/230V
Horsepower 3/4 HP
RPM 1800
Phase Single Phase
Frame 56
Enclosure TEAO
Hertz 60 Hz
Type Split Phase
Amperage 10.8/5.4 Amps
Bearings Ball Bearings
Speeds 1-Speed
Insulation Class Class B
Rotation Reversible
Mounting Rigid Base
Adding to cart… The item has been added
Description
  • 3/4 HP 1800 RPM (1 speed), 10.8/5.4 amps 115/230V Volts 60 Hz Split Phase Motor
  • 56 Frame, Rolled Steel, Keyed Shaft 5/8" diameter x 1 7/8" long
  • Service Factor = 1.25, Overload Protection: Auto
  • Rigid Base Mount, Ball Bearings, Class B Insulation, Reversible Rotation
  • 1 Year Manufacture Warranty

Single phase farm fan motor for poultry and livestock houses. Wiring diagram on motor name plate. TEAO = Totally-Enclosed Air-Over, S063KCR8039012B

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 115/230V
Horsepower 3/4 HP
RPM 1800
Phase Single Phase
Frame 56
Enclosure TEAO
Hertz 60 Hz
Type Split Phase
Amperage 10.8/5.4 Amps
Bearings Ball Bearings
Speeds 1-Speed
Insulation Class Class B
Rotation Reversible
Mounting Rigid Base
!
