FF10E1DV Nidec 10 hp 3600 RPM 3-phase 213JP Frame 208-230/460V ODP Vertical Close-Coupled Fire Pump Motor
FF10E1DV Nidec 10 hp 3600 RPM 3-phase 213JP Frame 208-230/460V ODP Vertical Close-Coupled Fire Pump Motor
FF10E1DV Nidec 10 hp 3600 RPM 3-phase 213JP Frame 208-230/460V ODP Vertical Close-Coupled Fire Pump Motor
FF10E1DV Nidec 10 hp 3600 RPM 3-phase 213JP Frame 208-230/460V ODP Vertical Close-Coupled Fire Pump Motor

Nidec

FF10E1DV Nidec 10 hp 3600 RPM 3-phase 213JP Frame 208-230/460V ODP Vertical Close-Coupled Fire Pump Motor

(No reviews) Write a Review
$1,725.00
$1,540.20
SKU FF10E1DV
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 10 HP
RPM 3600
Phase Three Phase
Frame 213JP
Enclosure ODP
Hertz 60 Hz
Amperage 25.3/12.6 Amps
Bearings Ball Bearings
Insulation Class Class F
Rotation Reversible
Adding to cart… The item has been added
Description
  • 10 HP 3600 RPM, 27.5-25.3/12.6 amps, 208-230/460V 60hz. 3 Phase.
  • NEMA 213JP Rolled Steel Frame, JP stainless steel shaft
  • 1.15 Service Factor, Class F insulation
  • Reversible Rotation,
  • Face Mount, No Base, Ball Bearings

Meets NFPA 20 standards. Close Coupled motors have the pump impeller mounted directly on the shaft. 1 Year Manufacture Warranty. ODP = Open Drip Proof, FB75

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 10 HP
RPM 3600
Phase Three Phase
Frame 213JP
Enclosure ODP
Hertz 60 Hz
Amperage 25.3/12.6 Amps
Bearings Ball Bearings
Insulation Class Class F
Rotation Reversible
!
