FF25E1DV Nidec 25 hp 3600 RPM 3-phase 256JP Frame 208-230/460V ODP Vertical Close-Coupled Fire Pump Motor
FF25E1DV Nidec 25 hp 3600 RPM 3-phase 256JP Frame 208-230/460V ODP Vertical Close-Coupled Fire Pump Motor
FF25E1DV Nidec 25 hp 3600 RPM 3-phase 256JP Frame 208-230/460V ODP Vertical Close-Coupled Fire Pump Motor
FF25E1DV Nidec 25 hp 3600 RPM 3-phase 256JP Frame 208-230/460V ODP Vertical Close-Coupled Fire Pump Motor

Nidec

FF25E1DV Nidec 25 hp 3600 RPM 3-phase 256JP Frame 208-230/460V ODP Vertical Close-Coupled Fire Pump Motor

(No reviews) Write a Review
$3,164.80
$2,825.67
SKU FF25E1DV
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 25 HP
RPM 3600
Phase Three Phase
Frame 256JP
Enclosure ODP
Hertz 60 Hz
Amperage 58.0/28.9 Amps
Bearings Ball Bearings
Insulation Class Class F
Rotation Reversible
Adding to cart… The item has been added
Description
  • 25 HP 3600 RPM, 67.0-58.0/28.9 amps, 208-230/460V 60 Hz, 3 Phase.
  • NEMA 256JP Rolled Steel Frame, JP stainless steel shaft
  • 1.15 Service Factor, Class F insulation
  • Reversible Rotation,
  • Face Mount, No Base, Ball Bearings,

Meets NFPA 20 standards. Close Coupled motors have the pump impeller mounted directly on the shaft. 1 Year Manufacture Warranty. ODP = Open Drip Proof, HC49

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 25 HP
RPM 3600
Phase Three Phase
Frame 256JP
Enclosure ODP
Hertz 60 Hz
Amperage 58.0/28.9 Amps
Bearings Ball Bearings
Insulation Class Class F
Rotation Reversible
!
