FF25E1DV Nidec 25 hp 3600 RPM 3-phase 256JP Frame 208-230/460V ODP Vertical Close-Coupled Fire Pump Motor

160.00 LBS
Calculated at Checkout
  • 25 HP 3600 RPM, 67.0-58.0/28.9 amps, 208-230/460V 60 Hz, 3 Phase.
  • NEMA 256JP Rolled Steel Frame, JP stainless steel shaft
  • 1.15 Service Factor, Class F insulation
  • Reversible Rotation,
  • Face Mount, No Base, Ball Bearings,

Meets NFPA 20 standards. Close Coupled motors have the pump impeller mounted directly on the shaft. 1 Year Manufacture Warranty. ODP = Open Drip Proof, HC49
