FF25E1GV Nidec 25 hp 3600 RPM 3-phase 256JP Frame 575V ODP Vertical Close-Coupled Fire Pump Motor
FF25E1GV Nidec 25 hp 3600 RPM 3-phase 256JP Frame 575V ODP Vertical Close-Coupled Fire Pump Motor
FF25E1GV Nidec 25 hp 3600 RPM 3-phase 256JP Frame 575V ODP Vertical Close-Coupled Fire Pump Motor
FF25E1GV Nidec 25 hp 3600 RPM 3-phase 256JP Frame 575V ODP Vertical Close-Coupled Fire Pump Motor

Nidec

FF25E1GV Nidec 25 hp 3600 RPM 3-phase 256JP Frame 575V ODP Vertical Close-Coupled Fire Pump Motor

(No reviews) Write a Review
$3,164.80
$2,825.67
SKU FF25E1GV
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 575V
Horsepower 25 HP
RPM 3600
Phase Three Phase
Frame 256JP
Enclosure ODP
Hertz 60 Hz
Amperage 23.2 Amps
Bearings Ball Bearings
Insulation Class Class F
Rotation Reversible
Adding to cart… The item has been added
Description
  • 25 HP 3600 RPM, 23.2 amps, 575V 60 Hz, 3 Phase.
  • NEMA 256JP Rolled Steel Frame, JP stainless steel shaft
  • 1.15 Service Factor, Class F insulation
  • Reversible Rotation,
  • Face Mount, No Base, Ball Bearings,

Meets NFPA 20 standards. Close Coupled motors have the pump impeller mounted directly on the shaft. 1 Year Manufacture Warranty. ODP = Open Drip Proof, HC51

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 575V
Horsepower 25 HP
RPM 3600
Phase Three Phase
Frame 256JP
Enclosure ODP
Hertz 60 Hz
Amperage 23.2 Amps
Bearings Ball Bearings
Insulation Class Class F
Rotation Reversible
!
