GK2054 Century 1/2 hp (1 speed) 115V 1800 RPM OPEN 56 Frame Resilient Base Blower Motor

GK2054 Century 1/2 hp (1 speed) 115V 1800 RPM OPEN 56 Frame Resilient Base Blower Motor

The GK2054 is a reliable 1/2 horsepower blower motor designed for HVAC applications requiring consistent airflow. It replaces standard blower motors in residential and commercial air handling units, providing efficient air movement with a single-speed operation.

Key Specifications

• Horsepower: 1/2 hp
• RPM: 1800
• Voltage: 115V
• Amperage: 7.2 amps
• Enclosure: Open Drip Proof (ODP)
• Frame / Diameter: NEMA 56 Frame
• Shaft Dimensions: 1 7/8" length x 5/8" diameter, keyed shaft
• Rotation: Reversible
• Bearings: Sleeve Bearings

Product Features & Fitment

This motor features a resilient base for stable mounting and reduced vibration during operation. It includes thermal overload protection and is designed for reversible shaft rotation to accommodate various blower configurations. The motor’s sleeve bearings ensure smooth and quiet performance, suitable for vertical or horizontal shaft orientation.

Warranty

1 Year Manufacturer Warranty
