Goodman AMST48CU1300 R-32 MULTI-POSITION 9 SPEED ECM MOTOR ECB BASED AIR HANDLER WITH INTERNAL TXV 4 TON

Goodman AMST48CU1300 R-32 Multi-Position Air Handler

The Goodman AMST48CU1300 is a high-efficiency 4 Ton multi-position air handler designed for flexible installation in residential and light commercial HVAC systems. Powered by a direct-drive 9-speed ECM motor and optimized for low-GWP R-32 refrigerant, it provides precise airflow management, quiet operation, and enhanced energy savings across cooling and heat pump applications.

Key Specifications

• Nominal Capacity: 4 Ton (48,000 BTU)
• Motor Type: Direct-drive, resilient-mount, 9-speed ECM blower motor
• Refrigerant Compatibility: Optimized for R-32 with factory-installed leak detection sensor for A2L mitigation
• Expansion Valve: Internal factory-installed thermal expansion valve (TXV) for cooling and heat pump applications
• Coil Construction: All-aluminum evaporator coil with 3/8 in. tube and high-performance coated fin stock
• Cabinet Configuration: Multi-position (Horizontal or vertical configuration capabilities)
• Cabinet Rating: Cabinet air leakage less than 2% (less than 4% at 0.5 inch H2O tested per ASHRAE 193)
• Cabinet Depth: 21" depth for easier attic access
• Certifications: AHRI Certified & ETL Listed
• Warranty: 5 Years All Parts Warranty

Product Features & Fitment

This air handler is engineered with a rigid SmartFrame cabinet featuring a galvanized, leather grain-embossed finish and foil-faced insulation that covers the internal casing to minimize cabinet condensation. Screw-less sides and back further reduce condensation in humid environments, while the coil mounting track enables quick repositioning. Designed for versatile installation, the unit supports both ducted and free-return (non-ducted return air) applications, and includes a DecaBDE-free thermoplastic drain pan with primary and secondary drain connections.

Maintenance and serviceability are streamlined with tool-less filter access, an easily removable drain pan, a factory-installed pull-type disconnect, and glue-less cabinet insulation retention. The unit is compatible with optional 3 kW to 25 kW electric heater kits (available without heat or with sequence-controlled, rust-resistant nickel-chromium heating elements), allowing custom heating configurations for any residential layout.
