H1052AV1 Century 2 HP 1140 RPM JuggerNaut Vertical Condenser Fan Electric Motor 460/208-230V

H1052AV1 Century 2 HP 1140 RPM JuggerNaut Vertical Condenser Fan Electric Motor 460/208-230V

The H1052AV1 is a 2 HP, 1140 RPM vertical condenser fan motor designed for reliable, energy-efficient operation in HVAC applications. It replaces Century/AO Smith H1052A motors and is suitable for continuous duty air-over use.

Key Specifications

• Horsepower: 2 HP
• RPM: 1140
• Voltage: 460/208-230V
• Amperage: 3.5/7.0 Amps
• Frame / Diameter: 56HZ Frame
• Shaft Dimensions: 5/8" x 6"
• Bearings: Double Sealed Ball Bearings

Product Features & Fitment

This motor features inverter duty capability with conductive bearing grease for inverter applications and includes a removable 56H rigid base for flexible mounting options. It is equipped with positioning lugs for easy belly-band mounting and shaft-up installation, along with a quick connect design and extra mounting nuts for convenience. Additional features include Class F moisture-resistant insulation, automatic overload protection, a large water slinger, and a voltage change module (VCM™) for versatile voltage settings. The motor is rated for a maximum ambient temperature of 70°C and supports 50/60 Hz operation.

Cross Reference

• Century/AO Smith H1052A

Warranty

• Specification Sheet
