H171 Marathon 1/4 hp (2 speed) 115V 1800/1200 RPM ODP 48Z Frame Resilient Base Blower Motor

H171 Marathon 1/4 hp (2 speed) 115V 1800/1200 RPM ODP 48Z Frame Resilient Base Blower Motor

This Marathon blower motor is designed for HVAC and industrial air-moving applications, providing reliable two-speed operation. It is suitable for replacing existing 1/4 hp motors with similar specifications, ensuring efficient airflow in various building ventilation systems.

Key Specifications

• Horsepower: 1/4 hp
• RPM: 1800/1200 (two-speed)
• Voltage: 115 V, 60 Hz
• Amperage: 4.2/2.7 A
• Enclosure: Open Drip Proof (ODP)
• Frame / Diameter: NEMA 48Z Frame
• Shaft Dimensions: 1 7/8" length x 1/2" diameter, flat shaft
• Bearings: Ball Bearings

Product Features & Fitment

The motor features a resilient base for vibration reduction and is reversible for versatile installation. It is equipped with Class B insulation and does not include thermal protection. The shaft orientation can be vertical or horizontal, accommodating various blower configurations.

Warranty

1 Year Manufacturer Warranty
