H217 Marathon 1/3 hp 1800 RPM 56CZ Frame 115V (No Base) ODP Exhaust Blower Motor

H217 Marathon 1/3 hp 1800 RPM 56CZ Frame 115V (No Base) ODP Exhaust Blower Motor

This Marathon 1/3 horsepower exhaust blower motor is designed for belt drive blower applications requiring a reliable and efficient motor replacement. It features a 56CZ frame and operates at 1800 RPM with reversible rotation, suitable for various HVAC and industrial motor setups.

Key Specifications

• Horsepower: 1/3 hp
• RPM: 1800
• Voltage: 115V
• Amperage: 6.6 amps
• Enclosure: Open Drip Proof (ODP)
• Frame / Diameter: NEMA 56CZ rolled steel
• Shaft Dimensions: 5/8" diameter x 2 1/4" length
• Rotation: Reversible
• Bearings: Ball Bearings

Product Features & Fitment

This split phase motor includes Class B insulation and a service factor of 1.35, ensuring durability and reliable performance. It does not come with a base and has no overload protection. The motor’s wiring diagram is conveniently located on the nameplate for easy installation.

Warranty

1 Year Manufacturer Warranty
