HD2V2BC Nidec 2 hp 1800 RPM 145TC (Rigid Base Cast Iron) 230/460V TEFC Inverter-Duty 3-Phase Motor

SKU:
HD2V2BC
Weight:
70.00 LBS
Shipping:
Calculated at Checkout
ON SALE:
LIMITED TIME DISCOUNT
Was: $540.00
Now: $482.50
Adding to cart… The item has been added
  • 2 hp 1800 RPM, 5.3/2.7 amps 230/460 Volts 60 Hz Three Phase Motor
  • NEMA 145TC Cast Iron Frame, Keyed Shaft 7/8" Diameter x 2 1/4"
  • Service Factor: 1.15 Overload protection = None
  • C-Face Mount, Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

Speed controllable C-Face motor for material handling, cranes and machine tools in hostile environments. 5:1 speed range at constant torque, 20:1 at variable torque. NEMA design B. Brake provisions. Wiring diagram on motor name plate. TEFC = Totally-Enclosed Fan-Cooled. GG61
