HD3P1H Nidec 3 hp 3600 RPM 182T Frame (Rigid Base) 200V TEFC 3-Phase Electric Motor

SKU:
HD3P1H
Weight:
70.00 LBS
Shipping:
Calculated at Checkout
ON SALE:
LIMITED TIME DISCOUNT
Was: $458.00
Now: $408.50
Adding to cart… The item has been added
  • 3 hp 3600 RPM, 9.3 amps 200 Volts 60 Hz Three Phase Motor
  • NEMA 182T Cast Iron frame Keyed Shaft 1 1/8" Diameter x 2 3/4"
  • Service Factor: 1.15, Overload protection = None
  • Rigid Base Mount, Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

Hostile duty motor can be used for many applications requiring a three phase electric motor. Inverter Duty. Self-certified Class 1, Division 2, Groups A, B, C, D. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan cooled. GF07
