HD40P2H Nidec 40 hp 1800 RPM 324T Frame (Rigid Base) 200-208V TEFC 3-Phase Electric Motor
HD40P2H Nidec 40 hp 1800 RPM 324T Frame (Rigid Base) 200-208V TEFC 3-Phase Electric Motor
HD40P2H Nidec 40 hp 1800 RPM 324T Frame (Rigid Base) 200-208V TEFC 3-Phase Electric Motor
HD40P2H Nidec 40 hp 1800 RPM 324T Frame (Rigid Base) 200-208V TEFC 3-Phase Electric Motor

Nidec

HD40P2H Nidec 40 hp 1800 RPM 324T Frame (Rigid Base) 200-208V TEFC 3-Phase Electric Motor

(No reviews) Write a Review
$2,513.90
$2,345.95
SKU HD40P2H
Availability Subject to Availability
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 200/208V
Horsepower 40 HP
RPM 1800
Phase Three Phase
Frame 324T
Enclosure TEFC
Hertz 60 Hz
Amperage 104 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Duty Inverter Duty
Adding to cart… The item has been added
Description
  • 40 hp 1800 RPM, 106-104 amps 200-208 Volts 60 Hz Three Phase Motor
  • NEMA 324T Cast Iron frame Keyed Shaft 2 1/8" Diameter x 5 5/8"
  • Service Factor: 1.15, Overload protection = None
  • Rigid Base Mount, Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

Hostile duty motor can be used for many applications requiring a three phase electric motor. Inverter Duty. Self-certified Class 1, Division 2, Groups A, B, C, D. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan cooled. GC11

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 200/208V
Horsepower 40 HP
RPM 1800
Phase Three Phase
Frame 324T
Enclosure TEFC
Hertz 60 Hz
Amperage 104 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Duty Inverter Duty
!
