HD50P1HS Nidec 50 hp 3600 RPM 326TS Frame (Rigid Base) 200-208V TEFC 3-Phase Electric Motor
HD50P1HS Nidec 50 hp 3600 RPM 326TS Frame (Rigid Base) 200-208V TEFC 3-Phase Electric Motor
HD50P1HS Nidec 50 hp 3600 RPM 326TS Frame (Rigid Base) 200-208V TEFC 3-Phase Electric Motor
HD50P1HS Nidec 50 hp 3600 RPM 326TS Frame (Rigid Base) 200-208V TEFC 3-Phase Electric Motor

Nidec

HD50P1HS Nidec 50 hp 3600 RPM 326TS Frame (Rigid Base) 200-208V TEFC 3-Phase Electric Motor

(No reviews) Write a Review
$3,474.15
$3,102.13
SKU HD50P1HS
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 200/208V
Horsepower 50 HP
RPM 3600
Phase Three Phase
Frame 326TS
Enclosure TEFC
Hertz 60 Hz
Amperage 123 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Duty Inverter Duty
Adding to cart… The item has been added
Description
  • 50 hp 3600 RPM, 129-123 amps 200-208 Volts 60 Hz Three Phase Motor
  • NEMA 326TS Cast Iron frame Keyed Shaft 1 7/8" Diameter x 4 1/8"
  • Service Factor: 1.15, Overload protection = None
  • Rigid Base Mount, Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

Hostile duty motor can be used for many applications requiring a three phase electric motor. Inverter Duty. Self-certified Class 1, Division 2, Groups A, B, C, D. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan cooled. GC10

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 200/208V
Horsepower 50 HP
RPM 3600
Phase Three Phase
Frame 326TS
Enclosure TEFC
Hertz 60 Hz
Amperage 123 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Duty Inverter Duty
!
