HO100P2SLG Nidec 100 hp 1800 RPM 460V 3-phase 404TP Frame Vertical Holloshaft Motor
HO100P2SLG Nidec 100 hp 1800 RPM 460V 3-phase 404TP Frame Vertical Holloshaft Motor
HO100P2SLG Nidec 100 hp 1800 RPM 460V 3-phase 404TP Frame Vertical Holloshaft Motor
HO100P2SLG Nidec 100 hp 1800 RPM 460V 3-phase 404TP Frame Vertical Holloshaft Motor

Nidec

HO100P2SLG Nidec 100 hp 1800 RPM 460V 3-phase 404TP Frame Vertical Holloshaft Motor

(No reviews) Write a Review
$12,753.50
$10,999.95
SKU HO100P2SLG
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 460V
Horsepower 100 HP
RPM 1800
Phase Three Phase
Frame 404TP
Hertz 60 Hz
Amperage 114 Amps
Bearings Ball Bearings
Insulation Class Class F
Adding to cart… The item has been added
Description
  • 100 HP 1800 RPM, 114 amps, 460V 60 Hz. 3-Phase
  • NEMA 404TP Frame, RUS type, 16.5" Dia. Base
  • 1.15 Service Factor, Class F insulation, Thermal Protection: None
  • Non-Reversible Ratchet Rotation, Weather Protected Enclosure
  • P-Base Mounting, Ball Bearings, High Thrust
  • Coupler: Non-Reverse Ratchet (NRR), Height - 36 15/16", Diameter - 1 1/2" , Keyway 3/8"

Vertical pump motor for use on turbine, mix flow, and propeller pumps. 1 Year Manufacture Warranty. HF48

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 460V
Horsepower 100 HP
RPM 1800
Phase Three Phase
Frame 404TP
Hertz 60 Hz
Amperage 114 Amps
Bearings Ball Bearings
Insulation Class Class F
!
