HO25V2BLF Nidec 25 hp 1800 RPM 230/460V 3-phase 284TPA Frame Inverter-Duty Vertical Holloshaft Motor
HO25V2BLF Nidec 25 hp 1800 RPM 230/460V 3-phase 284TPA Frame Inverter-Duty Vertical Holloshaft Motor
HO25V2BLF Nidec 25 hp 1800 RPM 230/460V 3-phase 284TPA Frame Inverter-Duty Vertical Holloshaft Motor
HO25V2BLF Nidec 25 hp 1800 RPM 230/460V 3-phase 284TPA Frame Inverter-Duty Vertical Holloshaft Motor

Nidec

HO25V2BLF Nidec 25 hp 1800 RPM 230/460V 3-phase 284TPA Frame Inverter-Duty Vertical Holloshaft Motor

(No reviews) Write a Review
$5,728.15
$5,113.94
SKU HO25V2BLF
Availability Please email for availability
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 230/460V
Horsepower 25 HP
RPM 1800
Phase Three Phase
Frame 284TPA
Hertz 60 Hz
Amperage 58.0/29.2 Amps
Bearings Ball Bearings
Insulation Class Class F
Duty Inverter Duty
Adding to cart… The item has been added
Description
  • 25 HP 1800 RPM, 58.0/29.2 amps, 230/460V 60 Hz. 3-Phase Inverter Duty
  • NEMA 284TPA Frame, AUSI type, 12.0" Dia. Base
  • 1.15 Service Factor, Class F insulation, Thermal Protection: None
  • Non-Reversible Ratchet Rotation, Weather Protected Enclosure
  • P-Base Mounting, Ball Bearings, High Thrust
  • Coupler: Non-Reverse Ratchet (NRR), Height - 24 3/4", Diameter - 1" , Keyway ¼"

Vertical pump motor for use on turbine, mix flow, and propeller pumps. 1 Year Manufacture Warranty. FB98

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 230/460V
Horsepower 25 HP
RPM 1800
Phase Three Phase
Frame 284TPA
Hertz 60 Hz
Amperage 58.0/29.2 Amps
Bearings Ball Bearings
Insulation Class Class F
Duty Inverter Duty
!
