HO40P2BLF Nidec 40 hp 1800 RPM 230/460V 3-phase 324TPH Frame Vertical Holloshaft Motor
HO40P2BLF Nidec 40 hp 1800 RPM 230/460V 3-phase 324TPH Frame Vertical Holloshaft Motor
HO40P2BLF Nidec 40 hp 1800 RPM 230/460V 3-phase 324TPH Frame Vertical Holloshaft Motor
HO40P2BLF Nidec 40 hp 1800 RPM 230/460V 3-phase 324TPH Frame Vertical Holloshaft Motor

Nidec

HO40P2BLF Nidec 40 hp 1800 RPM 230/460V 3-phase 324TPH Frame Vertical Holloshaft Motor

(No reviews) Write a Review
$6,224.95
$5,558.30
SKU HO40P2BLF
Availability Please email for availability
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 230/460V
Horsepower 40 HP
RPM 1800
Phase Three Phase
Frame 324TPH
Hertz 60 Hz
Amperage 97.0/49.0 Amps
Bearings Ball Bearings
Insulation Class Class F
Adding to cart… The item has been added
Description
  • 40 HP 1800 RPM, 97.0/49.0 amps, 230/460V 60 Hz. 3-Phase
  • NEMA 324TPH Frame, RUS type, 12.0" Dia. Base
  • 1.15 Service Factor, Class F insulation, Thermal Protection: None
  • Non-Reversible Ratchet Rotation, Weather Protected Enclosure
  • P-Base Mounting, Ball Bearings, High Thrust
  • Coupler: Non-Reverse Ratchet (NRR), Height - 28 7/32", Diameter - 1 1/4" , Keyway 1/4"

Vertical pump motor for use on turbine, mix flow, and propeller pumps. 1 Year Manufacture Warranty. HF93

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 230/460V
Horsepower 40 HP
RPM 1800
Phase Three Phase
Frame 324TPH
Hertz 60 Hz
Amperage 97.0/49.0 Amps
Bearings Ball Bearings
Insulation Class Class F
!
