HT50P2BLG Nidec 50 hp 1800 RPM 230/460V 3-phase 326TP Frame TEFC Vertical Holloshaft Sinewave Motor
HT50P2BLG Nidec 50 hp 1800 RPM 230/460V 3-phase 326TP Frame TEFC Vertical Holloshaft Sinewave Motor
HT50P2BLG Nidec 50 hp 1800 RPM 230/460V 3-phase 326TP Frame TEFC Vertical Holloshaft Sinewave Motor
HT50P2BLG Nidec 50 hp 1800 RPM 230/460V 3-phase 326TP Frame TEFC Vertical Holloshaft Sinewave Motor

Nidec

HT50P2BLG Nidec 50 hp 1800 RPM 230/460V 3-phase 326TP Frame TEFC Vertical Holloshaft Sinewave Motor

(No reviews) Write a Review
$10,137.25
$9,050.73
SKU HT50P2BLG
Availability Please email for availability
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 230/460V
Horsepower 50 HP
RPM 1800
Phase Three Phase
Frame 326TP
Enclosure TEFC
Hertz 60 Hz
Amperage 116/58.0 Amps
Bearings Ball Bearings
Insulation Class Class F
Adding to cart… The item has been added
Description
  • 50 HP 1800 RPM, 116/58.0 amps, 230/460V 60 Hz. 3 Phase
  • NEMA 326TP Frame, TUS type, 16 1/2" Dia. Base, TEFC
  • 1.15 Service Factor, Class F insulation, Thermal Protection: None
  • Non-Reversible Ratchet Rotation, Weather Protected Enclosure
  • P-Base Mounting, Ball Bearings, High Thrust
  • Coupler: Non-Reverse Ratchet (NRR), Height - 28 7/32", Diameter - 1 1/4" , Keyway 1/4"

Vertical pump motor for use on turbine, mix flow, and propeller pumps. TEFC = Totally-Enclosed Fan-Cooled, 1 Year Manufacture Warranty. FK26

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 230/460V
Horsepower 50 HP
RPM 1800
Phase Three Phase
Frame 326TP
Enclosure TEFC
Hertz 60 Hz
Amperage 116/58.0 Amps
Bearings Ball Bearings
Insulation Class Class F
!
