HT60P2CLG Nidec 60 hp 1800 RPM 460V 3-phase 364TP Frame TEFC Vertical Holloshaft Sinewave Motor
HT60P2CLG Nidec 60 hp 1800 RPM 460V 3-phase 364TP Frame TEFC Vertical Holloshaft Sinewave Motor
HT60P2CLG Nidec 60 hp 1800 RPM 460V 3-phase 364TP Frame TEFC Vertical Holloshaft Sinewave Motor
HT60P2CLG Nidec 60 hp 1800 RPM 460V 3-phase 364TP Frame TEFC Vertical Holloshaft Sinewave Motor

Nidec

HT60P2CLG Nidec 60 hp 1800 RPM 460V 3-phase 364TP Frame TEFC Vertical Holloshaft Sinewave Motor

(No reviews) Write a Review
$12,572.95
$11,225.96
SKU HT60P2CLG
Availability Please email for availability
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 460V
Horsepower 60 HP
RPM 1800
Phase Three Phase
Frame 364TP
Enclosure TEFC
Hertz 60 Hz
Amperage 68.0 Amps
Bearings Ball Bearings
Insulation Class Class F
Adding to cart… The item has been added
Description
  • 60 HP 1800 RPM, 68.0 amps, 460V 60 Hz. 3 Phase
  • NEMA 364TP Frame, TUS type, 16 1/2" Dia. Base, TEFC
  • 1.15 Service Factor, Class F insulation, Thermal Protection: None
  • Non-Reversible Ratchet Rotation, Weather Protected Enclosure
  • P-Base Mounting, Ball Bearings, High Thrust
  • Coupler: Non-Reverse Ratchet (NRR), Height - 30", Diameter - 1 1/4" , Keyway 1/4"

Vertical pump motor for use on turbine, mix flow, and propeller pumps. TEFC = Totally-Enclosed Fan-Cooled, 1 Year Manufacture Warranty. FK27

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 460V
Horsepower 60 HP
RPM 1800
Phase Three Phase
Frame 364TP
Enclosure TEFC
Hertz 60 Hz
Amperage 68.0 Amps
Bearings Ball Bearings
Insulation Class Class F
!
