sale
Sold out
Nidec
HT100P2CLG Nidec 75 hp 1800 RPM 460V 3-phase 365TP Frame TEFC Vertical Holloshaft Sinewave Motor
(No reviews)
Write a Review
Write a Review
Nidec
HT100P2CLG Nidec 75 hp 1800 RPM 460V 3-phase 365TP Frame TEFC Vertical Holloshaft Sinewave Motor
$18,400.00
$18,054.94
SKU
HT100P2CLG
Availability
Please email for availability
Shipping
Calculated at Checkout
Compliance Tab
/content/product_tabs/p65warnings.html
ON SALE
LIMITED TIME DISCOUNT
- 100 HP 1800 RPM, 113 amps, 460V 60 Hz. 3 Phase
- NEMA 405TP Frame, TUS type, 16 1/2" Dia. Base, TEFC
- 1.15 Service Factor, Class F insulation, Thermal Protection: None
- Non-Reversible Ratchet Rotation, Weather Protected Enclosure
- P-Base Mounting, Ball Bearings, High Thrust
- Coupler: Non-Reverse Ratchet (NRR), Height - 39 15/16", Diameter - 1 1/2" , Keyway 1/4"
Vertical pump motor for use on turbine, mix flow, and propeller pumps. TEFC = Totally-Enclosed Fan-Cooled, 1 Year Manufacture Warranty. FL97
| Compliance Tab | /content/product_tabs/p65warnings.html |
|---|---|
| ON SALE | LIMITED TIME DISCOUNT |
Related Products
Add to Cart
The item has been added
HT75P2CLG Nidec 75 hp 1800 RPM 460V 3-phase 365TP Frame TEFC Vertical Holloshaft Sinewave Motor
75 HP 1800 RPM, 85.0 amps, 460V 60 Hz. 3 Phase
NEMA 365TP Frame, TUS type, 16 1/2" Dia. Base, TEFC
1.15 Service Factor, Class F insulation, Thermal Protection: None
Non-Reversible Ratchet Rotation,...
$0.00
sale
Add to Cart
The item has been added
HO75P2SLG Nidec 75 hp 1800 RPM 460V 3-phase 365TP Frame Vertical Holloshaft Motor
75 HP 1800 RPM, 87.0 amps, 460V 60 Hz. 3-Phase
NEMA 365TP Frame, RUS type, 16.5" Dia. Base
1.15 Service Factor, Class F insulation, Thermal Protection: None
Non-Reversible Ratchet Rotation, Weather...
$10,048.70
$8,972.30
sale
Add to Cart
The item has been added
HO75P2BLG Nidec 75 hp 1800 RPM 230/460V 3-phase 365TP Frame Vertical Holloshaft Motor
75 HP 1800 RPM, 174/87.0 amps, 230/460V 60 Hz. 3-Phase
NEMA 365TP Frame, RUS type, 16.5" Dia. Base
1.15 Service Factor, Class F insulation, Thermal Protection: None
Non-Reversible Ratchet Rotation,...
$10,048.70
$7,899.95
sale
Add to Cart
The item has been added
HT60P2CLG Nidec 60 hp 1800 RPM 460V 3-phase 364TP Frame TEFC Vertical Holloshaft Sinewave Motor
60 HP 1800 RPM, 68.0 amps, 460V 60 Hz. 3 Phase
NEMA 364TP Frame, TUS type, 16 1/2" Dia. Base, TEFC
1.15 Service Factor, Class F insulation, Thermal Protection: None
Non-Reversible Ratchet Rotation,...
$12,572.95
$11,225.96
sale
Add to Cart
The item has been added
CHT75V2CLG Nidec 75 hp 1800 RPM 460V 3-phase 365TP Frame TEFC Holloshaft CORRO-DUTY Motor
75 HP 1800 RPM, 85 amps, 460V 60 Hz. 3 Phase
NEMA 365TP Frame, TUCI type, 16 1/2" Dia. Base, TEFC
1.15 Service Factor, Class H insulation, Thermal Protection: None
Non-Reversible Ratchet Rotation,...
$15,895.30
$14,192.38
