HW10V3E2 Nidec 10 hp 1200 RPM 256T Frame (Rigid Base) 230/460V TEFC 3-Phase Cooling Tower Motor
HW10V3E2 Nidec 10 hp 1200 RPM 256T Frame (Rigid Base) 230/460V TEFC 3-Phase Cooling Tower Motor
HW10V3E2 Nidec 10 hp 1200 RPM 256T Frame (Rigid Base) 230/460V TEFC 3-Phase Cooling Tower Motor
HW10V3E2 Nidec 10 hp 1200 RPM 256T Frame (Rigid Base) 230/460V TEFC 3-Phase Cooling Tower Motor

Nidec

HW10V3E2 Nidec 10 hp 1200 RPM 256T Frame (Rigid Base) 230/460V TEFC 3-Phase Cooling Tower Motor

(No reviews) Write a Review
$3,455.75
$3,085.22
SKU HW10V3E2
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 230/460V
Horsepower 10 HP
RPM 1200
Phase Three Phase
Frame 256T
Enclosure TEFC
Hertz 60 Hz
Amperage 24.5/12.3 Amps
Bearings Ball Bearings
Speeds 1-Speed
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Duty Inverter Duty
Adding to cart… The item has been added
Description
  • 10 hp 1200 RPM, 24.5/12.3 amps 230/460 Volts 60 Hz Three Phase Motor
  • NEMA 256T Cast Iron frame Keyed Shaft 1 5/8" Diameter x 4"
  • Service Factor: 1.15, Overload protection = None
  • Rigid Base Mount, Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

For use in cooling tower and evaporation cooler applications. Corrosion resistant, Inverter Duty (10:1 speed range). Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan Cooled. FH52

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 230/460V
Horsepower 10 HP
RPM 1200
Phase Three Phase
Frame 256T
Enclosure TEFC
Hertz 60 Hz
Amperage 24.5/12.3 Amps
Bearings Ball Bearings
Speeds 1-Speed
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Duty Inverter Duty
!
