174102.00 Leeson | DC Motor Control 174102 - NEMA 4X - 90/180VDC, 1/8 hp to 2 hp

174102.00 Leeson DC Motor Control - NEMA 4X, 90/180VDC, 1/8 hp to 2 hp

The Leeson 174102.00 DC Motor Control is a versatile speed controller designed for permanent magnet DC motors. It is ideal for industrial applications requiring reliable motor speed regulation, including washdown and outdoor environments.

Key Specifications

• Horsepower: 1/8 hp to 1 hp @ 115V, 1/4 hp to 2 hp @ 230V
• Voltage: 115/230 Volts AC, 60 Hz
• Enclosure: NEMA 4X (washdown duty, dust proof)

Product Features & Fitment

This controller features a dual voltage switch for operation on either 115V or 230V single-phase power at 50/60 Hz. It is designed for use with 90V DC motors when powered at 115V and 180V DC motors when powered at 230V. The NEMA 4X enclosure provides robust protection against dust and moisture, making it suitable for washdown or outdoor installations. Chassis-only units are also available for integration into existing equipment or enclosures. Installation and adjustment instructions are included.
