Leeson Parallel Shaft 1/12 hp, 14 RPM 115/230V Electric Gear Motor # 096002

SKU:
096002
Manufacturer
Leeson
Weight:
24.00 LBS
Shipping:
Free Shipping
$347.94
  • 1/12 hp, 14 RPM, 1.3/.65 amps,115/230 Volts 50/60hz.
  • Gear Ratio = 124
  • Torque 330 inch pounds
  • Over Hung Pounds = 459
  • Rotation = Reversible
  • TENV, Keyed Shaft, Ball Bearings

One Year Manufacture Warranty. Features: This worm-type right-angle gearing features hardened, steel worm with bronze worm wheel for long life and quiet operation. Precision machined aluminum housings are used. Gearbox has ball bearings. The housing is sealed and lubrication is permanent with an oil bath. IP55 Washdown Duty. White epoxy paint. Optional L Bracket # M1760011, Optional Conduit Box # 175893.
