108708.00 Leeson | Parallel Shaft 1/2 hp, 33 RPM 90 Volts DC Electric Gear Motor

• 1/2 hp, 33 RPM, 5.0 amps, 90 Volts DC
• Gear Ratio = 53
• Torque 822 inch pounds
• Over Hung Pounds = 650
• Shaft 3/4" x 1.5"; Rotation = Reversible
• Keyed Shaft, Ball Bearings
• TEFC = Totally Enclosed Fan Cooled
• Class F Insulation; Service Factor 1.0
• One year manufacture warranty

Features: Precision machined in-line steel gears, with a first stage steel helical gear followed by spur-type gears. Lubrication is permanent semi-fluid grease, reducing possibility of leakage. Output shafts have needle bearings for high load capacities. Shafts are hardened steel. Can use with Leeson speed control 174307, 174308.

C4D17FZ24C, 108708.00
