108711.00 Leeson | Parallel Shaft 1/2 hp, 92 RPM 90 Volts DC TEFC Electric Gear Motor

108711.00 Leeson Parallel Shaft 1/2 hp, 92 RPM 90 Volts DC TEFC Electric Gear Motor

This Leeson electric gear motor delivers reliable 1/2 horsepower performance with a low-speed output of 92 RPM, designed for industrial applications requiring precise torque and reversible rotation. It is an ideal replacement for equipment needing a durable, totally enclosed fan-cooled (TEFC) motor with a parallel shaft configuration.

Key Specifications

• Horsepower: 1/2 hp
• RPM: 92
• Voltage: 90 Volts DC
• Amperage: 5.0 amps
• Enclosure: Totally Enclosed Fan Cooled (TEFC)
• Shaft Dimensions: 3/4" diameter x 1.5" length
• Rotation: Reversible
• Bearings: Ball bearings

Product Features & Fitment

This motor features precision-machined in-line steel gears, including a first stage steel helical gear followed by spur-type gears, ensuring smooth and efficient power transmission. The output shaft is keyed and supported by needle bearings for high load capacity, with hardened steel shafts for durability. Lubrication is provided by permanent semi-fluid grease to minimize leakage. Compatible with Leeson speed controls models 174307 and 174308 for enhanced speed regulation.

Warranty

1 Year Manufacturer Warranty
