M1135117.00 Leeson | Parallel Shaft 1/4 hp, 21 RPM 90 Volts DC TENV Electric Gear Motor

M1135117.00 Leeson Parallel Shaft 1/4 hp, 21 RPM 90 Volts DC TENV Electric Gear Motor

This Leeson parallel shaft gear motor delivers 1/4 horsepower at 21 RPM with a 90 Volt DC power supply. It serves as a suitable replacement for Baldor GPP7457 and Bodine 5047 motors, ideal for industrial applications requiring precise low-speed torque.

Key Specifications

• Horsepower: 1/4 hp
• RPM: 21
• Voltage: 90 Volts DC
• Amperage: 1.10 amps
• Enclosure: Totally Enclosed Non Ventilated (TENV)
• Shaft Dimensions: 3/4" diameter x 1.625" length, keyed
• Rotation: Reversible
• Bearings: Ball bearings with needle bearings on output shafts

Product Features & Fitment

The motor features precision-machined in-line steel gears, including a first-stage steel helical gear followed by spur-type gears, lubricated with permanent semi-fluid grease to minimize leakage. Hardened steel shafts with needle bearings provide high load capacity and durability. An optional conduit box (SKU M1760007) is available for installation flexibility. This motor is compatible with Leeson speed controls 174307 and 174308. Please verify shaft and mounting compatibility before replacement.

Cross Reference

• Baldor GPP7457, Bodine 5047 - Please cross check your existing motor specs, shaft and mounting to make sure the replacement Leeson will interchange with your existing equipment

Warranty

1 Year Manufacturer Warranty
