108704.00 Leeson | Parallel Shaft 1/4 hp, 60 RPM 90 Volts DC TENV Electric Gear Motor

SKU:
108704
Weight:
40.00 LBS
Shipping:
Free Shipping
ON SALE:
DISCOUNTED PRICES AND FREE GROUND SHIPPING
Was: $807.88
Now: $734.43
  • 1/4 hp, 60 RPM, 2.7 amps, 90 Volts DC
  • Gear Ratio = 29; Torque 238 inch pounds
  • Over Hung Pounds = 625
  • Shaft 3/4" x 1.5"; Rotation = Reversible
  • TENV = Totally Enclosed Non Ventilated
  • Class F Insulation; Service Factor 1.0
  • Keyed Shaft, Ball Bearings
  • One Year Manufacture Warranty.

Features: Precision machined in-line steel gears, with a first stage steel helical gear followed by spur-type gears. Lubrication is permanent semi-fluid grease, reducing possibility of leakage.Output shafts have needle bearings for high load capacities. Shafts are hardened steel. Can use with Leeson speed control 174307, 174308.

C4D17NZ21C, 108704.00
