M1125071.00 Leeson | Parallel Shaft 1/8 hp, 51 RPM 90 Volts DC TENV Electric Gear Motor

M1125071.00 Leeson Parallel Shaft 1/8 hp, 51 RPM 90 Volts DC TENV Electric Gear Motor

This Leeson electric gear motor delivers reliable power with a 1/8 horsepower rating and a low-speed output of 51 RPM. Designed for industrial applications requiring precise torque and reversible rotation, it is a direct replacement for similar parallel shaft gear motors.

Key Specifications

• Horsepower: 1/8 hp
• RPM: 51
• Voltage: 90 Volts DC
• Amperage: 1.4 amps
• Enclosure: TENV (Totally Enclosed Non-Ventilated)
• Shaft Dimensions: 5/8" diameter x 1.5" length, keyed
• Rotation: Reversible
• Bearings: Ball bearings

Product Features & Fitment

The motor features precision-machined in-line steel gears, including a first stage steel helical gear followed by spur-type gears, ensuring smooth and efficient power transmission. It is lubricated with permanent semi-fluid grease to minimize leakage and maintenance. Hardened steel output shafts incorporate needle bearings for high load capacity and durability.

An optional conduit box (part # M1760021) is available to facilitate wiring and installation. This motor is compatible with Leeson speed controls models 174307 and 174308, allowing for adjustable speed operation in various industrial setups.

Warranty

1 Year Manufacturer Warranty
