- 1/4 hp, 62 RPM, 21.0 amps, 12 Volts DC
- Gear Ratio = 40 Torque 135 inch pounds
- Over Hung Pounds = 235
- Shaft 5/8" x 1.8"; Rotation = Reversible
- TENV = Totally Enclosed Non Ventilated
- Class F Insulation; Service Factor 1.0
- Optional conduit box available
- Keyed Shaft, Ball Bearings
- One Year Manufacture Warranty.
Features: This worm-type right-angle gearing features hardened, steel worm with bronze worm wheel for long life and quiet operation. Precision machined aluminum housings are used. Gearbox has ball bearings. The housing is sealed and lubrication is permanent with an oil bath. The output shaft is field interchangeable from left hand style to right hand style by reassembly. Optional mounting base # M1760006 and optional conduit box # M1760007 available. Can use with Leeson speed control 175291.
