LM24802 Leeson 5 hp 1800 RPM 208-230V TEFC 184T Frame (Extra Torque Farm Duty) Motor
LM24802 Leeson 5 hp 1800 RPM 208-230V TEFC 184T Frame (Extra Torque Farm Duty) Motor
LM24802 Leeson 5 hp 1800 RPM 208-230V TEFC 184T Frame (Extra Torque Farm Duty) Motor
LM24802 Leeson 5 hp 1800 RPM 208-230V TEFC 184T Frame (Extra Torque Farm Duty) Motor
LM24802 Leeson 5 hp 1800 RPM 208-230V TEFC 184T Frame (Extra Torque Farm Duty) Motor
LM24802 Leeson 5 hp 1800 RPM 208-230V TEFC 184T Frame (Extra Torque Farm Duty) Motor
LM24802 Leeson 5 hp 1800 RPM 208-230V TEFC 184T Frame (Extra Torque Farm Duty) Motor
LM24802 Leeson 5 hp 1800 RPM 208-230V TEFC 184T Frame (Extra Torque Farm Duty) Motor

Leeson/Marathon

LM24802 Leeson 5 hp 1800 RPM 208-230V TEFC 184T Frame (Extra Torque Farm Duty) Motor

(No reviews) Write a Review
$1,167.02
SKU LM24802
UPC 6.92E+11
Shipping Calculated at Checkout
Voltage 208/230V
Horsepower 5 HP
RPM 1800
Phase Single Phase
Frame 184T
Enclosure TEFC
Hertz 60 Hz
Amperage 21.8 Amps
Bearings Ball Bearings
Insulation Class Class F
Rotation Reversible
Mounting Rigid Base
Adding to cart… The item has been added
Description

    5 hp 1800 RPM, 23.8-21.8 amps, 208-230 Volts 60 Hz.Capacitor Start / Capacitor Run
    NEMA 182T Frame, TEFC,  Keyed Shaft 1 1/8" Diameter x 2 3/4"
    Service Factor = 1.15, Overload Protection: Manual
    Rigid Base, Reversible Rotation, Ball Bearings, Class F Insulation
    1 Year Manufacture Warranty

Leeson single phase farm duty motor. Extra High Starting Torque above that of normal farm duty motors, TEFC = Totally-Enclosed Fan-Cooled, LM24802

Specifications
Voltage 208/230V
Horsepower 5 HP
RPM 1800
Phase Single Phase
Frame 184T
Enclosure TEFC
Hertz 60 Hz
Amperage 21.8 Amps
Bearings Ball Bearings
Insulation Class Class F
Rotation Reversible
Mounting Rigid Base
!
