Z112A Marathon 2 hp 1800 RPM 115/230V TEFC 184TZ Frame (Extra Torque Farm Duty) Motor
Z112A Marathon 2 hp 1800 RPM 115/230V TEFC 184TZ Frame (Extra Torque Farm Duty) Motor
Z112A Marathon 2 hp 1800 RPM 115/230V TEFC 184TZ Frame (Extra Torque Farm Duty) Motor
Z112A Marathon 2 hp 1800 RPM 115/230V TEFC 184TZ Frame (Extra Torque Farm Duty) Motor
Z112A Marathon 2 hp 1800 RPM 115/230V TEFC 184TZ Frame (Extra Torque Farm Duty) Motor
Z112A Marathon 2 hp 1800 RPM 115/230V TEFC 184TZ Frame (Extra Torque Farm Duty) Motor
Z112A Marathon 2 hp 1800 RPM 115/230V TEFC 184TZ Frame (Extra Torque Farm Duty) Motor
Z112A Marathon 2 hp 1800 RPM 115/230V TEFC 184TZ Frame (Extra Torque Farm Duty) Motor

Marathon

Z112A Marathon 2 hp 1800 RPM 115/230V TEFC 184TZ Frame (Extra Torque Farm Duty) Motor

(No reviews) Write a Review
$862.50
$804.94
SKU MZ112A
UPC 7.23E+11
Availability CURRENTLY OUT OF STOCK
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 115/230V
Horsepower 2 HP
RPM 1800
Phase Single Phase
Frame 184TZ
Enclosure TEFC
Hertz 60 Hz
Amperage 24/12 Amps
Bearings Ball Bearings
Insulation Class Class F
Rotation Reversible
Mounting Rigid Base
Adding to cart… The item has been added
Description
  • 2 hp 1800 RPM, 24/12 amps, 115/230 Volts 60 Hz.Capacitor Start / Induction Run
  • NEMA 182TZ Frame, TEFC,  Keyed Shaft 7/8" Diameter x 2 3/4"
  • Service Factor = 1.15, Overload Protection: Manual
  • Rigid Base, Reversible Rotation, Ball Bearings, Class F Insulation
  • 1 Year Manufacture Warranty

Marathon single phase farm duty motor. Extra High Starting Torque above that of normal farm duty motors yet with shaft diameter of next smaller frame size, TEFC = Totally-Enclosed Fan-Cooled, 182TCFW9061

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 115/230V
Horsepower 2 HP
RPM 1800
Phase Single Phase
Frame 184TZ
Enclosure TEFC
Hertz 60 Hz
Amperage 24/12 Amps
Bearings Ball Bearings
Insulation Class Class F
Rotation Reversible
Mounting Rigid Base
!
