M1125269.00 Leeson 1/4 hp 42 RPM 90 VDC 32 Frame (Rigid Base) TENV Wash-Down Gearmotor

M1125269.00 Leeson 1/4 hp 42 RPM 90 VDC 32 Frame (Rigid Base) TENV Wash-Down Gearmotor

This Leeson gearmotor delivers 1/4 horsepower at 42 RPM with a 90 VDC power supply, designed for wash-down environments requiring slow speed and high torque. It is ideal for replacing or upgrading motors in wet and misty industrial settings.

Key Specifications

• Horsepower: 1/4 hp
• RPM: 42
• Voltage: 90 VDC
• Amperage: 2.6 amps
• Enclosure: Totally Enclosed Non-Ventilated (TENV)
• Frame / Diameter: NEMA 32 Frame
• Rotation: Reversible
• Bearings: Ball Bearings

Product Features & Fitment

The gearmotor features a rigid base mounting and a keyed shaft for secure installation. It includes Class F insulation and is designed without overload protection. Wiring diagrams are provided on the motor nameplate for ease of setup.

Warranty

1 Year Manufacturer Warranty
