NP0032G TECO-Westinghouse 3 hp 3600 RPM 182T 230/460V TEFC Severe Duty SGR 3-Ph Motor

NP0032G TECO-Westinghouse 3 hp 3600 RPM 182T 230/460V TEFC Severe Duty SGR 3-Ph Motor

The NP0032G is a premium NEMA electric motor designed for industrial applications requiring reliable, severe-duty performance. It replaces standard motors in three-phase systems and is ideal for use in electrically challenging environments due to its specialized bearing protection.

Key Specifications

• Horsepower: 3 hp
• RPM: 3600
• Voltage: 230/460 V
• Amperage: 7.06/3.53 A
• Enclosure: Totally Enclosed Fan Cooled (TEFC), IP56
• Frame / Diameter: NEMA 182T, Cast Iron Frame
• Shaft Dimensions: 2 1/4" length x 7/8" diameter, keyed
• Rotation: Reversible
• Bearings: Ball Bearings with SGR bearing protection ring

Product Features & Fitment

This motor features a rigid base for secure mounting and is suitable for inverter use in compliance with NEMA MG-1 Part 31.4.4.2 standards. It supports a wide inverter duty speed range of 20:1 for variable torque and 10:1 for constant torque applications. The cast iron frame and Class F insulation provide durability and thermal protection, although thermal overload protection is not included. This motor is UL recognized, CSA approved, and CE marked for safety and quality assurance.

Warranty

1 Year Manufacturer Warranty
