NP0754 TECO-Westinghouse 75 hp 1800 RPM 365T 230/460V TEFC Severe Duty 3-Ph Motor

NP0754 TECO-Westinghouse 75 hp 1800 RPM 365T 230/460V TEFC Severe Duty 3-Ph Motor

The NP0754 is a TECO-Westinghouse general-purpose electric motor designed for severe duty applications. It is a premium NEMA motor suitable for replacing similar 75 hp, 1800 RPM three-phase motors in industrial settings.

Key Specifications

• Horsepower: 75 hp
• RPM: 1800
• Voltage: 230/460 V
• Amperage: 170/85.1 A
• Enclosure: Totally Enclosed Fan Cooled (TEFC), IP56
• Frame / Diameter: NEMA 365T Frame, 5 5/8 x 2 3/8" Diameter
• Shaft Dimensions: Keyed Shaft
• Rotation: Reversible
• Bearings: Ball Bearings

Product Features & Fitment

This motor features a cast iron rigid base frame and Class F insulation, providing durability and thermal protection suitable for demanding environments. It is designed for inverter duty with a speed range of 20:1 for variable torque and 10:1 for constant torque, complying with NEMA MG-1 Part 31.4.4.2 standards. The motor is U.L. Recognized, CSA Approved, and CE Marked, ensuring compliance with industry safety and quality standards.

Warranty

1 Year Manufacturer Warranty
