NP1/54 TECO Westinghouse 1 1/2 hp 1800 RPM 143T Frame 208-230/460V TEFC 3-Phase Motor
NP1/54 TECO Westinghouse 1 1/2 hp 1800 RPM 143T Frame 208-230/460V TEFC 3-Phase Motor
NP1/54 TECO Westinghouse 1 1/2 hp 1800 RPM 143T Frame 208-230/460V TEFC 3-Phase Motor
NP1/54 TECO Westinghouse 1 1/2 hp 1800 RPM 143T Frame 208-230/460V TEFC 3-Phase Motor

TECO WESTINGHOUSE

NP1/54 TECO Westinghouse 1 1/2 hp 1800 RPM 143T Frame 208-230/460V TEFC 3-Phase Motor

(No reviews) Write a Review
$363.17
SKU NP1/54
Shipping Calculated at Checkout
Voltage 208/230/460V
Horsepower 1/2 HP
RPM 1800
Phase Three Phase
Frame 143T
Enclosure TEFC
Hertz 60 Hz
Amperage 4.16/2.08 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class B
Mounting Rigid Base
Duty SEVERE DUTY
Adding to cart… The item has been added
Description

TECO WESTINGHOUSE MAX-PE, NEMA PREMIUM ELECTRIC MOTOR
SEVERE DUTY RATED

  • 1 1/2 hp 1800 RPM, 4.16/2.08 amps 230/460 Volts 60hz. Three Phase
  • NEMA 143T Frame, Keyed Shaft 7/8" Diameter x 2 1/4"
  • Cast Iron Construction, Enclosure: Totally Enclosed Fan Cooled (IP54)
  • Service Factor: 1.15, Thermal Overload Protection: None
  • Rigid Base, Reversible, Ball Bearings, Class B Insulation
  • Suitable for Inverter Use per NEMA MG-1 Part 31.4.4.2
  • Inverter Duty Speed Range: 20:1 Variable Torque, 10:1 Constant Torque
  • Motors are U.L. Recognized, CSA Approved and CE Marked
  • 1 Year Manufacture Warranty

Applications: Fans & Blowers, Pumps, Crushers, Compressors, Mixers, Conveyors

Specifications
Voltage 208/230/460V
Horsepower 1/2 HP
RPM 1800
Phase Three Phase
Frame 143T
Enclosure TEFC
Hertz 60 Hz
Amperage 4.16/2.08 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class B
Mounting Rigid Base
Duty SEVERE DUTY
!
