NPV0502C TECO-Westinghouse 50 HP 3600 RPM 326TSC 230/460V TEFC Vertical Severe Duty 3-Ph Motor

SKU:
NPV0502C
Weight:
603.00 LBS
Shipping:
Calculated at Checkout
$3,515.33
Adding to cart… The item has been added

TECO WESTINGHOUSE, NEMA PREMIUM ELECTRIC MOTOR

  • 50 hp 3600 RPM, 109/54.7 amps 230/460 Volts 60 Hz. Three Phase
  • NEMA 326TSC Frame, 3 1/2 x 1 7/8" Dia. Keyed Shaft
  • Cast Iron Frame, Totally Enclosed Fan Cooled (IP56)
  • Service Factor: 1.15, Thermal Overload Protection: None
  • C-Face, Reversible, Ball Bearings, Class F Insulation
  • Suitable for Inverter Use per NEMA MG-1 Part 31.4.4.2
  • Inverter Duty Speed Range: 20:1 Variable Torque, 10:1 Constant Torque
  • Motors are U.L. Recognized, CSA Approved and CE Marked
  • 1 Year Manufacture Warranty

For use in Severe Duty Applications Having Explosive Gases. Certified for Class 1, Division 2, Groups B,C,D
