NPV0506C TECO-Westinghouse 50 HP 1200 RPM 365TC 230/460V TEFC Vertical Severe Duty 3-Ph Motor
NPV0506C TECO-Westinghouse 50 HP 1200 RPM 365TC 230/460V TEFC Vertical Severe Duty 3-Ph Motor
NPV0506C TECO-Westinghouse 50 HP 1200 RPM 365TC 230/460V TEFC Vertical Severe Duty 3-Ph Motor
NPV0506C TECO-Westinghouse 50 HP 1200 RPM 365TC 230/460V TEFC Vertical Severe Duty 3-Ph Motor

TECO WESTINGHOUSE

NPV0506C TECO-Westinghouse 50 HP 1200 RPM 365TC 230/460V TEFC Vertical Severe Duty 3-Ph Motor

(No reviews) Write a Review
$6,192.15
SKU NPV0506C
Shipping Calculated at Checkout
Voltage 230/460V
Horsepower 50 HP
RPM 1200
Phase Three Phase
Frame 365TC
Enclosure TEFC
Hertz 60 Hz
Amperage 115.6/57.8 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting C-Face
Duty Severe Duty
Adding to cart… The item has been added
Description

TECO WESTINGHOUSE, NEMA PREMIUM ELECTRIC MOTOR

  • 50 hp 1200 RPM, 115.6/57.8 amps 230/460 Volts 60 Hz. Three Phase
  • NEMA 365TC Frame, 5 5/8 x 2 3/8" Dia. Keyed Shaft
  • Cast Iron Frame, Totally Enclosed Fan Cooled (IP56)
  • Service Factor: 1.15, Thermal Overload Protection: None
  • C-Face, Reversible, Ball Bearings, Class F Insulation
  • Suitable for Inverter Use per NEMA MG-1 Part 31.4.4.2
  • Inverter Duty Speed Range: 20:1 Variable Torque, 10:1 Constant Torque
  • Motors are U.L. Recognized, CSA Approved and CE Marked
  • 1 Year Manufacture Warranty

For use in Severe Duty Applications Having Explosive Gases. Certified for Class 1, Division 2, Groups B,C,D

Specifications
Voltage 230/460V
Horsepower 50 HP
RPM 1200
Phase Three Phase
Frame 365TC
Enclosure TEFC
Hertz 60 Hz
Amperage 115.6/57.8 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting C-Face
Duty Severe Duty
!
