sale
Marathon
R319A Marathon | 2 hp 1.5 kW 230/460V 1800 RPM 3-Phase 90S Frame TEFC (rigid base) Motor
(No reviews)
Write a Review
Write a Review
Marathon
R319A Marathon | 2 hp 1.5 kW 230/460V 1800 RPM 3-Phase 90S Frame TEFC (rigid base) Motor
$1,035.00
$839.44
SKU
MR319A
UPC
7.23E+11
Shipping
Free Shipping
Compliance Tab
/content/product_tabs/p65warnings.html
ON SALE
DISCOUNTED PRICES & SHIPS SAME DAY FOR ORDERS PLACED BEFORE 2 PM
Voltage
230/460V
Horsepower
2 HP
RPM
1800
Phase
Three Phase
Frame
90S
Enclosure
TEFC
Hertz
60 Hz
Amperage
5.4/2.7 Amps
Bearings
Ball Bearings
Service Factor
1.15
Insulation Class
Class F
Mounting
Rigid Base
- 2 hp 1.5 kW, 1800 RPM, 5.4/2.7 amps 230/460 Volts 60hz. Three Phase
- Metric 90S Cast Aluminum frame, Keyed Shaft 24 mm Diameter x 50 mm
- Service Factor: 1.15, Thermal Overload Protection: None
- Rigid Base, Reversible, Ball Bearings, Class F Insulation, B3 Mounting
- 1 Year Manufacture Warranty
This is a metric general purpose three phase motor with a rigid base mount. Shaft has keyway. General purpose motors are for use in situations not having special requirements. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan-Cooled
Marathon # 090LT17FH6326, Replaces Leeson 192205.00, 192205.30, 192071.00
| Compliance Tab | /content/product_tabs/p65warnings.html |
|---|---|
| ON SALE | DISCOUNTED PRICES & SHIPS SAME DAY FOR ORDERS PLACED BEFORE 2 PM |
| Voltage | 230/460V |
| Horsepower | 2 HP |
| RPM | 1800 |
| Phase | Three Phase |
| Frame | 90S |
| Enclosure | TEFC |
| Hertz | 60 Hz |
| Amperage | 5.4/2.7 Amps |
| Bearings | Ball Bearings |
| Service Factor | 1.15 |
| Insulation Class | Class F |
| Mounting | Rigid Base |
