R338M2 CENTURY POOL PUMP MOTOR 10 HP

R338M2 CENTURY POOL PUMP MOTOR 10 HP

The R338M2 Century Pool Pump Motor is a 10 HP replacement motor designed for commercial pool pump applications. It is compatible with Hydrotech (Purex) East Side "L" Series and "C" Series pumps, providing reliable performance for demanding environments.

Key Specifications

• Horsepower: 10 HP
• RPM: 3450
• Voltage: 208-220/440 Volts
• Amperage: 28.0-26.0/13.0 Amps
• Frame / Diameter: 213TY Frame
• Bearings: Ball Bearings
• Insulation Class: B

Product Features & Fitment

This motor features a square flange design with an external slinger and is rated for operation in ambient temperatures up to 40°C with a service factor of 1.15. It is keyed for pump series C and cross-referenced as 353636. Shipping is restricted to freight truck delivery; please ensure the delivery address can accommodate a semi-truck.

Regulatory Notice:
Effective July 19, 2021, new US Department of Energy regulations affect single speed, two-speed, and booster pumps. This motor does not comply with California Title 20 or New York NYSERDA Section 509.23 efficiency regulations, which require variable speed motors. Customers are advised to verify local codes and consider upgrading to a variable speed motor to ensure compliance. For further assistance, please contact us via phone or chat.

Cross Reference

• 353636
• ATTENTION: Shipping Restrictions Apply!
• ** Effective July 19, 2021 the US Dept of Energy regulations on single speed, two-speed and booster pumps go into effect **
