S0/74 TECO-Westinghouse 3/4 HP 1800 RPM 56 Frame 115/230V TEFC Rolled Steel 1-Ph Motor
S0/74 TECO-Westinghouse 3/4 HP 1800 RPM 56 Frame 115/230V TEFC Rolled Steel 1-Ph Motor
S0/74 TECO-Westinghouse 3/4 HP 1800 RPM 56 Frame 115/230V TEFC Rolled Steel 1-Ph Motor
S0/74 TECO-Westinghouse 3/4 HP 1800 RPM 56 Frame 115/230V TEFC Rolled Steel 1-Ph Motor

TECO WESTINGHOUSE

S0/74 TECO-Westinghouse 3/4 HP 1800 RPM 56 Frame 115/230V TEFC Rolled Steel 1-Ph Motor

(No reviews) Write a Review
$313.31
SKU S0/74
Shipping Free Shipping
Voltage 115/230V
Horsepower 3/4 HP
RPM 1800
Phase Single Phase
Frame 56
Enclosure TEFC
Hertz 60 Hz
Amperage 12.2/6.1 Amps
Bearings Ball Bearings
Speeds 1-Speed
Insulation Class Class B
Adding to cart… The item has been added
Description

TECO WESTINGHOUSE, FARM DUTY ELECTRIC MOTOR

  • 3/4 hp 1800 RPM, 1-Speed, 12.2/6.1 amps, 115/230 Volts 60 Hz.
  • 56 Frame of Rolled Steel, Shaft: 5/8" x 1 7/8" with Slot
  • Rotation = Reversible, Overload Protector: Manual
  • Service Factor = 1.15, Insulation Class B
  • Ball Bearing, Capacitor Start
  • 1 Year Manufacture Warranty

Farm Duty Motor. Totally Enclosed Fan Cooled (TEFC)

Specifications
Voltage 115/230V
Horsepower 3/4 HP
RPM 1800
Phase Single Phase
Frame 56
Enclosure TEFC
Hertz 60 Hz
Amperage 12.2/6.1 Amps
Bearings Ball Bearings
Speeds 1-Speed
Insulation Class Class B
!
