S0014 TECO-Westinghouse 1 HP 1800 RPM 56 Frame 115/230V TEFC Rolled Steel 1-Ph Motor

S0014 TECO-Westinghouse 1 HP 1800 RPM 56 Frame 115/230V TEFC Rolled Steel 1-Ph Motor

This TECO-Westinghouse 1 HP electric motor is designed for farm duty applications, providing reliable performance in a variety of industrial and agricultural settings. It serves as a direct replacement for similar 1-phase motors requiring a 56 frame and TEFC enclosure.

Key Specifications

• Horsepower: 1 HP
• RPM: 1800
• Voltage: 115/230 V
• Amperage: 14.0/7.0 A
• Enclosure: Totally Enclosed Fan Cooled (TEFC)
• Frame / Diameter: 56 Frame, Rolled Steel
• Shaft Dimensions: 5/8" diameter x 1 7/8" length with slot
• Rotation: Reversible
• Bearings: Ball Bearing

Product Features & Fitment

This motor features a capacitor start and manual overload protector for enhanced durability and protection. It includes a service factor of 1.15 and insulation class B, ensuring reliable operation under demanding conditions. The reversible shaft rotation allows flexible installation options to suit various equipment configurations.

Warranty

1 Year Manufacturer Warranty
