S5P1ACR Nidec 5 hp 3600 RPM 184TC Frame (No Base) 208-230/460V TEFC 3-Phase Electric Motor
S5P1ACR Nidec 5 hp 3600 RPM 184TC Frame (No Base) 208-230/460V TEFC 3-Phase Electric Motor
S5P1ACR Nidec 5 hp 3600 RPM 184TC Frame (No Base) 208-230/460V TEFC 3-Phase Electric Motor
S5P1ACR Nidec 5 hp 3600 RPM 184TC Frame (No Base) 208-230/460V TEFC 3-Phase Electric Motor

Nidec

S5P1ACR Nidec 5 hp 3600 RPM 184TC Frame (No Base) 208-230/460V TEFC 3-Phase Electric Motor

(No reviews) Write a Review
$676.20
$604.10
SKU S5P1ACR
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 5 HP
RPM 3600
Phase Three Phase
Frame 184TC
Enclosure TEFC
Hertz 60 Hz
Amperage 12.1/6.1 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Adding to cart… The item has been added
Description
  • 5 hp 1800 RPM, 13.6-12.1/6.1 amps 208-230/460 Volts 60 Hz Three Phase Motor
  • NEMA 184TC frame Keyed Shaft 1 1/8" Diameter x 2 5/8"
  • Service Factor: 1.15, Overload protection = None
  • Rigid Base Mount, Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

General purpose C- Face motor can be used for many applications requiring a three phase electric motor.  Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan cooled. DT87

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 5 HP
RPM 3600
Phase Three Phase
Frame 184TC
Enclosure TEFC
Hertz 60 Hz
Amperage 12.1/6.1 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
!
