S7P2AC Nidec 7 1/2 hp 1800 RPM 213TC Frame 208-230/460V TEFC 3-Phase Electric Motor

SKU:: S7P2AC
UPC:
Weight:: 90.00 LBS
Width:: 22.00 (in)
Height:: 13.00 (in)
Depth:: 15.00 (in)
Shipping:: Calculated at Checkout
ON SALE:: LIMITED TIME DISCOUNT
Voltage:: 208/230/460V
Horsepower:: 1/2 HP
RPM:: 1800
Phase:: Three Phase
Frame:: 213TC
Enclosure:: TEFC
Hertz:: 60 Hz
Amperage:: 18.1/9.1 Amps
Bearings:: Ball Bearings
Service Factor:: 1.15
Insulation Class:: Class F
Mounting:: Rigid Base

Current Stock:

Was: $895.85

Now: $799.83

Quantity:

Adding to cart… The item has been added

Description
Literature
Compliance & Restrictions

S7P2AC Nidec 7 1/2 hp 1800 RPM 213TC Frame 208-230/460V TEFC 3-Phase Electric Motor

This Nidec general-purpose electric motor delivers 7 1/2 horsepower at 1800 RPM and is designed for three-phase industrial applications. It is a direct replacement for motors requiring a 213TC frame and TEFC enclosure, suitable for various mechanical and HVAC equipment.

Key Specifications

Horsepower: 7 1/2 hp
RPM: 1800
Voltage: 208-230/460 V
Amperage: 20.0-18.1/9.1 A
Enclosure: Totally Enclosed Fan Cooled (TEFC)
Frame / Diameter: NEMA 213TC
Shaft Dimensions: Keyed shaft, 1 3/8" diameter x 3 3/8" length
Bearings: Ball bearings
Rotation: Reversible

Product Features & Fitment

This motor features a rigid base mount for stable installation and includes Class F insulation for enhanced thermal protection. The wiring diagram is conveniently located on the motor nameplate to assist with proper electrical connections. The motor is designed without built-in overload protection and has a service factor of 1.15.
