SP0022 TECO-Westinghouse 2 HP 3600 RPM 145T Frame 115/208-230V ODP Rolled Steel 1-Ph Motor
SP0022 TECO-Westinghouse 2 HP 3600 RPM 145T Frame 115/208-230V ODP Rolled Steel 1-Ph Motor
SP0022 TECO-Westinghouse 2 HP 3600 RPM 145T Frame 115/208-230V ODP Rolled Steel 1-Ph Motor
SP0022 TECO-Westinghouse 2 HP 3600 RPM 145T Frame 115/208-230V ODP Rolled Steel 1-Ph Motor

TECO WESTINGHOUSE

SP0022 TECO-Westinghouse 2 HP 3600 RPM 145T Frame 115/208-230V ODP Rolled Steel 1-Ph Motor

(No reviews) Write a Review
$411.11
SKU SP0022
Shipping Free Shipping
Voltage 115/208/230V
Horsepower 2 HP
RPM 3600
Phase Single Phase
Frame 145T
Enclosure ODP
Hertz 60 Hz
Amperage 16.4/8.2 Amps
Bearings Ball Bearings
Speeds 1-Speed
Insulation Class Class F
Adding to cart… The item has been added
Description

TECO WESTINGHOUSE, NEMA PREMIUM ELECTRIC MOTOR

  • 2 hp 3600 RPM, 1-Speed, 16.4/8.2 amps, 115/208-230 Volts 60 Hz.
  • 145T Frame of Rolled Steel, Shaft: 7/8" x 2 1/4" with flat
  • Rotation = Reversible, Overload Protector: Automatic
  • Service Factor = 1.15, Insulation Class F
  • Ball Bearing, Capacitor Start/Run
  • 1 Year Manufacture Warranty

General purpose motor for HVAC. Open Drip Proof (ODP)

Specifications
Voltage 115/208/230V
Horsepower 2 HP
RPM 3600
Phase Single Phase
Frame 145T
Enclosure ODP
Hertz 60 Hz
Amperage 16.4/8.2 Amps
Bearings Ball Bearings
Speeds 1-Speed
Insulation Class Class F
!
