SPH1/52 TECO-Westinghouse 1 1/2 HP 3600 RPM 56H Frame 115/208-230V ODP Rolled Steel 1-Ph Motor
SPH1/52 TECO-Westinghouse 1 1/2 HP 3600 RPM 56H Frame 115/208-230V ODP Rolled Steel 1-Ph Motor
SPH1/52 TECO-Westinghouse 1 1/2 HP 3600 RPM 56H Frame 115/208-230V ODP Rolled Steel 1-Ph Motor
SPH1/52 TECO-Westinghouse 1 1/2 HP 3600 RPM 56H Frame 115/208-230V ODP Rolled Steel 1-Ph Motor

TECO WESTINGHOUSE

SPH1/52 TECO-Westinghouse 1 1/2 HP 3600 RPM 56H Frame 115/208-230V ODP Rolled Steel 1-Ph Motor

(No reviews) Write a Review
$382.93
SKU SPH1/52
Shipping Free Shipping
Voltage 115/208/230V
Horsepower 1/2 HP
RPM 3600
Phase Single Phase
Frame 56H
Enclosure ODP
Hertz 60 Hz
Amperage 12.2/6.1 Amps
Bearings Ball Bearings
Speeds 1-Speed
Insulation Class Class F
Adding to cart… The item has been added
Description

TECO WESTINGHOUSE, NEMA PREMIUM ELECTRIC MOTOR

  • 1 1/2 hp 3600 RPM, 1-Speed, 12.2/6.1 amps, 115/208-230 Volts 60 Hz.
  • 56H Frame of Rolled Steel, Shaft: 5/8" x 1 7/8" with Slot
  • Rotation = Reversible, Overload Protector: Automatic
  • Service Factor = 1.15, Insulation Class F
  • Ball Bearing, Capacitor Start/Run
  • 1 Year Manufacture Warranty

General purpose motor for HVAC. Open Drip Proof (ODP)

Specifications
Voltage 115/208/230V
Horsepower 1/2 HP
RPM 3600
Phase Single Phase
Frame 56H
Enclosure ODP
Hertz 60 Hz
Amperage 12.2/6.1 Amps
Bearings Ball Bearings
Speeds 1-Speed
Insulation Class Class F
!
