SPHT0/22 TECO-Westinghouse 1/4 HP 3600 RPM 56 Frame 115/208-230V TEFC Rolled Steel 1-Ph Motor
SPHT0/22 TECO-Westinghouse 1/4 HP 3600 RPM 56 Frame 115/208-230V TEFC Rolled Steel 1-Ph Motor
SPHT0/22 TECO-Westinghouse 1/4 HP 3600 RPM 56 Frame 115/208-230V TEFC Rolled Steel 1-Ph Motor
SPHT0/22 TECO-Westinghouse 1/4 HP 3600 RPM 56 Frame 115/208-230V TEFC Rolled Steel 1-Ph Motor

TECO WESTINGHOUSE

SPHT0/22 TECO-Westinghouse 1/4 HP 3600 RPM 56 Frame 115/208-230V TEFC Rolled Steel 1-Ph Motor

(No reviews) Write a Review
$265.24
SKU SPHT0/22
Shipping Free Shipping
Voltage 115/208/230V
Horsepower 1/4 HP
RPM 3600
Phase Single Phase
Frame 56
Enclosure TEFC
Hertz 60 Hz
Amperage 2.6/1.3 Amps
Bearings Ball Bearings
Speeds 1-Speed
Insulation Class Class F
Adding to cart… The item has been added
Description

TECO WESTINGHOUSE, NEMA PREMIUM ELECTRIC MOTOR

  • 1/4 hp 3600 RPM, 1-Speed, 2.6/1.3 amps, 115/208-230 Volts 60 Hz.
  • 56 Frame of Rolled Steel, Shaft: 5/8" x 1 7/8" with Slot
  • Rotation = Reversible, Overload Protector: Automatic
  • Service Factor = 1.15, Insulation Class F
  • Ball Bearing, Capacitor Start/Run
  • 1 Year Manufacture Warranty

General purpose motor for HVAC. Totally Enclosed Fan-Cooled (TEFC)

Specifications
Voltage 115/208/230V
Horsepower 1/4 HP
RPM 3600
Phase Single Phase
Frame 56
Enclosure TEFC
Hertz 60 Hz
Amperage 2.6/1.3 Amps
Bearings Ball Bearings
Speeds 1-Speed
Insulation Class Class F
!
