ST0032 TECO-Westinghouse 3 HP 3600 RPM 182T 208-230V TEFC Rolled Steel 1-Ph Motor
ST0032 TECO-Westinghouse 3 HP 3600 RPM 182T 208-230V TEFC Rolled Steel 1-Ph Motor
ST0032 TECO-Westinghouse 3 HP 3600 RPM 182T 208-230V TEFC Rolled Steel 1-Ph Motor
ST0032 TECO-Westinghouse 3 HP 3600 RPM 182T 208-230V TEFC Rolled Steel 1-Ph Motor

TECO WESTINGHOUSE

ST0032 TECO-Westinghouse 3 HP 3600 RPM 182T 208-230V TEFC Rolled Steel 1-Ph Motor

(No reviews) Write a Review
$708.38
SKU ST0032
Shipping Free Shipping
Voltage 208/230V
Horsepower 3 HP
RPM 3600
Phase Single Phase
Frame 182T
Enclosure TEFC
Hertz 60 Hz
Amperage 12.5 Amps
Bearings Ball Bearings
Speeds 1-Speed
Insulation Class Class F
Adding to cart… The item has been added
Description

TECO WESTINGHOUSE, NEMA PREMIUM ELECTRIC MOTOR

  • 3 hp 3600 RPM, 1-Speed, 12.5 amps, 208-230 Volts 60 Hz.
  • 182T Frame of Rolled Steel, Shaft: 1 1/8" x 2 3/4" with Slot
  • Rotation = Reversible, Overload Protector: Automatic
  • Service Factor = 1.15, Insulation Class F
  • Ball Bearing, Capacitor Start/Run
  • 1 Year Manufacture Warranty

General purpose motor for HVAC. Totally Enclosed Fan Cooled (TEFC)

Specifications
Voltage 208/230V
Horsepower 3 HP
RPM 3600
Phase Single Phase
Frame 182T
Enclosure TEFC
Hertz 60 Hz
Amperage 12.5 Amps
Bearings Ball Bearings
Speeds 1-Speed
Insulation Class Class F
!
